HD72XL Cargo Truck Mounted with Foldable Crane
HYUNDAI TRUCK & BUS - QATAR
HD72XL Single Cabin Truck
- GVM: 7.2 Tons
- Chassis Payload ~ 5 Tons
- Net Payload: 3.5 Tons
- No of Seats: 2+1 nos.
- Wheel Base: 3735 mm
- Width: 2000 mm (wide cabin)
Additional Equipment:HD72XL Cargo Body
- Wooden Floor with Reinforcement.
- Side Guard from Steel Structure.
- External Length = 4.4m
- External Width = 2.05m
- Internal Length = 4.3m
- Internal Width = 1.92m
Additional Equipment:HD72XL Boom (Stiff) crane
Model: Tadano TM-ZE294 MH (Made in Japan)
Lifting Capacity: 3.03 Ton @ 1.5m | 1.73 Ton @ 2.5 m
Lifting Capacity: 880 kg @ 3.5 m | 480 kg @ 5.0 m
Lifting Capacity: 200 kg @ 8.7 m
Maximum slewing angle: 360°
With one pair of outriggers.
Maximum hydraulic reach ~ 8.5 m. (300 kg)
Oil Tank: 22 lit.
Crane self-weight: 1035 kg
